A tractor is a self-propelled power machine used to pull and drive working machinery to complete various mobile operations. Tractors include wheeled tractors and crawler tractors,It can also be used as a fixed working power. It can pull or drive a variety of agricultural machinery such as tillage, planting, fertilization, and harvesting. It is widely used in agriculture, forestry, animal husbandry and other fields. It is an indispensable mechanical equipment in agricultural production.
product specifications
Model |
|
Unit |
TT504 |
TT604 |
TT704 |
TT804 |
TT904 |
TT1004 |
|
Type |
/ |
Drive type (4×4) |
|||||
|
Power |
kW |
36.8 |
44.1 |
51.5 |
58.8 |
66.2 |
74 |
Dimensions |
Dimension(L×W×H) |
mm |
Awning: 4020×1830×2750 Cab: 4020×1830×2800 |
|||||
|
Wheel base |
mm |
2110 |
|||||
|
Min.ground clearance |
mm |
380 |
|||||
|
Min.Weight |
kg |
Awning: 2920kg Cab: 3000kg |
|||||
|
Tread |
mm |
Front tread:1400(1200~1600)adjustable Rear tread:1400(1300~1600)adjustable |
|||||
Power |
Clutch |
/ |
Dry-type,double-acting |
|||||
|
Engine |
/ |
4 Cylinder |
|||||
|
Rated speed |
r/min |
2400 |
|||||
Working part |
Gear |
/ |
TB12F+12R |
|||||
|
PTO Type |
/ |
6 Spline、Φ38、I type(Option: 8 Spline) |
|||||
|
PTO Rated power |
kW |
≥31.3 |
≥37.5 |
≥43.8 |
≥50.2 |
≥56.3 |
≥63 |
|
PTO Speed |
r/min |
540/720 or 540/1000 |
|||||
Hydrualic system |
Three point linkage |
/ |
Rear,three-point suspension,cat 2 |
|||||
|
Hydrualic output |
/ |
2-Way valve |
|||||
|
Hydrualic adjustment type |
/ |
Forced hydrualic system,position control,floating control |
|||||
|
Max.lifting force at frame center |
kN |
≥8.9 |
≥10.6 |
≥12.4 |
≥14.3 |
≥15.9 |
≥20.2 |
Tyre |
Tyre (Front/ Rear) |
/ |
8.3-24/14.9-30 |
|||||
|
Optional tyre (Ⅰ) |
/ |
280/85R20 380/85R30 |
|||||
Other options |
|
/ |
Air brake, cab, awning, safety rack |
|||||
Designed for diverse agricultural requirements, our 4WD agricultural tractor delivers the traction and structural strength needed for fieldwork, crop care, and farm transport. Its four-wheel-drive configuration helps improve grip on soft ground and uneven surfaces, while the reinforced chassis and durable axles support demanding workloads and the use of heavy agricultural implements.
With engine options ranging from 50 HP to 210 HP, buyers can select a model that matches their land size, equipment requirements, and daily workload. Optional enclosed cabins provide added comfort during extended operation, while the large-capacity fuel tank helps reduce refueling stops during busy farming periods.
From soil cultivation and seedbed preparation to mowing, harrowing, and trailer hauling, this 4WD farm tractor accommodates a wide range of agricultural implements. Its combination of selectable engine power, practical configuration options, and multi-purpose functionality helps farmers handle seasonal tasks with greater flexibility and efficiency.


Different jobs have different functional requirements for tractors, and suitable tractor attachments can enable a tractor to do more work. We provide tractor implements and farm tractor implements covering scenarios such as tilling, mowing, clearing, transporting, and land maintenance, helping to solve problems such as high labor costs, low work efficiency, and insufficient equipment utilization. We can flexibly match tractor models, horsepower, and specific working conditions to provide efficient and practical tractor attachment solutions for agriculture, ranching, landscaping, and land maintenance.
Reinforced Chassis and 4WD: Heavy-duty axles and four-wheel drive provide reliable traction and stability on uneven farmland.
Powerful Hydraulic System: Delivers up to 20.2 kN lifting force for handling a variety of agricultural implements.
Flexible PTO Options: Multiple PTO power and speed configurations support different farming operations.
Large Fuel Tank: Reduces refueling frequency during long working hours.
Durable Protective Coating: Electrophoretic paint improves resistance to corrosion and outdoor wear.
Comfortable Operation: A suspension seat reduces vibration, while an optional enclosed cabin provides additional weather protection.

Large-Scale Field Operations: Capable of deep plowing, subsoiling, rotary tillage, seeding, fertilizing, and harvesting traction—fully mechanized operations tailored for extensive, contiguous farmland.
Orchards & Commercial Forests: Features a high ground clearance combined with an adjustable wheel track design, ideally suited for inter-row cultivation, weeding, transport, and other tasks within large-scale orchards and commercial forestry plantations.
Heavy-Duty Towing & Versatile Expansion: Compatible with a wide array of implements—including heavy-duty plows, combined tillage machines, balers, large trailers, and irrigation equipment—enabling multi-purpose functionality from a single machine to effectively reduce equipment investment costs.
Agricultural Infrastructure & Light Engineering: The robust, heavy-duty chassis effortlessly handles various scenarios, such as farmland water conservancy projects, site leveling, and the heavy-load transport of materials.
Q1: How durable is the equipment, and is it easy to maintain?
A1: The entire vehicle features an electrophoretic anti-rust coating process, and both the chassis and axles are engineered with a heavy-duty, reinforced design to withstand harsh operating environments. Key components are equipped with convenient access ports for inspection, making routine maintenance procedures simple. Furthermore, we provide comprehensive after-sales manuals and a nationwide warranty service; with an ample supply of spare parts, you need not worry about any future maintenance issues.
Q2: Will operational training and technical guidance be provided after purchase?
A2: Yes. Upon delivery of the equipment, we will provide basic training on operation, maintenance, and safe usage to help you get started quickly. Additionally, we offer long-term technical support; should you encounter any issues during operation, you may contact our after-sales team at any time to obtain guidance.
