Specifications
Model |
CPD-15B |
CPD-20B |
CPD-25B |
CPD-30B |
Load |
1500kg |
2000kg |
2500kg |
3000kg |
Load center |
500mm |
500mm |
500mm |
500mm |
Front wheel size |
6.50-10 |
6.50-10 |
6.50-10 |
6.50-10 |
Rear wheel size |
5.00-8 |
5.00-8 |
5.00-8 |
5.00-8 |
Front track width |
1020mm |
1020mm |
1020mm |
1050mm |
Rear track width |
870mm |
930mm |
930mm |
930mm |
Wheelbase |
1580mm |
1740mm |
1820mm |
1950mm |
Overhang |
475mm |
460mm |
470mm |
470mm |
Free lift height |
140mm |
140mm |
140mm |
140mm |
Lifting height |
3000mm |
3000mm |
3000mm |
3000mm |
Overhead guard height |
2090mm |
2090mm |
2090mm |
2090mm |
Seat height |
990mm |
990mm |
990mm |
990mm |
Overall length (including forks) |
3630(1220)mm |
3820(1220)mm |
3920(1220)mm |
3995(1220)mm |
Minimum turning radius |
2210mm |
2310mm |
2350mm |
2530mm |
Efficient material handling starts with dependable lifting power, easy control, and durable construction. Designed for warehouses, factories, logistics centers, distribution facilities, and construction sites, this forklift provides stable lifting, precise maneuverability, and reliable performance for loading, stacking, and transporting materials. Its solid structure is built for frequent daily use, helping operators improve handling efficiency while keeping operating costs under control.
Backed by Dongcheng Machinery, our forklifts are developed around the practical needs of modern material handling. With smooth operation, strong load-handling capability, and dependable components, they provide a reliable solution for different working environments. Whether used for warehouse loading, factory material movement, or logistics operations, Dongcheng forklifts combine performance, durability, and long-term value for demanding applications.
